Application of Overset Technology on Simplex Turbopump Design

A viewgraph presentation shows computer generated images of the Simplex Turbopump. Machine schematics are shown with scaled details of the nozzle ring assay and the turbine gas flow path. Grid generation is used to show nozzle grids, blade contours, blade grids and simplex full configuration and geometry. A flow simulation shows mach contours in absolute and relative frames.

Binding Type: Paperback
Publisher: Bibliogov
Published: 08/06/2013
ISBN: 9781287279082
Pages: 24
Weight: 0.14lbs
Size: 9.69h x 7.44w x 0.05d
