An Evaluation of the Roll-Rate Stabilization System of the Sidewinder Missile at Mach Numbers from 0.9 to 2.3

A linear stability analysis and flight-test investigation has been performed on a rolleron-type roll-rate stabilization system for a canard-type missile configuration through a Mach number range from 0.9 to 2.3. This type damper provides roll damping by the action of gyro-actuated uncoupled wing-tip ailerons. A dynamic roll instability predicted by the analysis was confirmed by flight testing and was subsequently eliminated by the introduction of control-surface damping about the rolleron hinge line. The control-surface damping was provided by an orifice-type damper contained within the control surface. Steady-state rolling velocities were at all times less than 1 radian per second between the Mach numbers of 0.9 to 2.3 on the configurations tested. No adverse longitudinal effects were experienced in flight because of the tendency of the free-floating rollerons to couple into the pitching motion at the low angles of attack and disturbance levels investigated herein after the introduction of control-surface damping.

Binding Type: Paperback
Publisher: Bibliogov
Published: 06/26/2013
ISBN: 9781289032036
Pages: 54
Weight: 0.25lbs
Size: 9.69h x 7.44w x 0.11d
